Omron E5*C Series User Manual

A Appendices
A - 4
E5@C-T Digital Temperature Controllers User’s Manual (H185)
A-1-2 Characteristics
Indication accuracy
(at ambient temperature of
23°C)
Thermocouple: (±0.3% of indication value or ±1°C, whichever is greater) ±1 digit max.
*1
Platinum resistance thermometer: (±0.2% of indication value or ±0.8°C, whichever is
greater) ±1 digit max.
Analog input: ±0.2% FS ±1 digit max.
CT input: ±5% FS ±1 digit max.
Potentiometer: Analog input: ±5% FS ±1 digit max.
Transfer output accuracy ±0.3% FS max.
Temperature variation
influence
* 2
R, S, B, W, or PLII thermocouple input: (±1% of indication value or ±10°C, whichever is
greater) ±1 digit max.
Other thermocouple input: (±1% of indication value or ±4°C, whichever is greater) ±1 digit
max.
*3
Platinum resistance thermometer input: (±1 % of indication value or ±2°C, whichever is
greater) ±1 digit max.
Analog input: ±1% FS ±1 digit max.
CT input: ±5% FS ±1 digit max.
Voltage variation influence
* 2
Input sampling period 50 ms
Hysteresis
Temperature input: 0.1 to 999.9°C or °F (in units of 0.1°C or °F)
Analog input: 0.01% to 99.99% FS (in units of 0.01% FS)
Proportional band (P)
Temperature input: 0.1 to 999.9°C or °F (in units of 0.1°C or °F)
Analog input: 0.1% to 999.9% FS (in units of 0.1% FS)
Integral time (I)
Standard, heating/cooling, or close position-proportional control: 0 to 9999 s (in units of
1 s), 0.0 to 999.9 s (in
units of 0.1 s)
Floating position-proportional control: 1 to 9999 s (in units of 1 s), 0.1 to 999.9 s (in units of
0.1 s)
*4
Derivative time (D)
0 to 9,999 s (in units of 1 s), 0.0 to 999.9 s (in units of 0.1 s)
*4
Proportional band (cooling)
(C-P)
Temperature input: 0.1 to 999.9°C or °F (in units of 0.1°C or °F)
Analog input: 0.1% to 999.9% FS (in units of 0.1% FS)
Integral time (cooling) (C-I)
0 to 9,999 s (in units of 1 s), 0.0 to 999.9 s (in units of 0.1 s)
*4
Derivative time (cooling)
(C-D)
0 to 9,999 s (in units of 1 s), 0.0 to 999.9 s (in units of 0.1 s)
*4
Control Period 0.1, 0.2, 0.5, or 1 to 99 s (in units of 1 s)
Manual reset value 0.0% to 100.0% (in units of 0.1%)
Alarm setting range −1,999 to 9,999 (decimal point position depends on input type)
Influence of signal source
resistance
Thermocouple: 0.1°C/Ω max. (100 Ω max.), Platinum resistance thermometer: 0.1°C/Ω
max. (10 Ω max.)
Insulation resistance 20 MΩ min. (at 500 VDC)
Dielectric strength 3,000 VAC, 50/60 Hz for 1 min between terminals of different charge
Vibration
Malfunction
10 to 55 Hz, 20 m/s
2
for 10 min each in X, Y and Z directions
Durability
10 to 55 Hz, 20 m/s
2
for 2 hr each in X, Y, and Z directions
Shock
Malfunction
100 m/s
2
, 3 times each in X, Y, and Z directions
Durability
300 m/s
2
, 3 times each in X, Y, and Z directions
Weight
E5CC-T
Controller: Approx. 120 g, Adapter: Approx. 10 g
Terminal Cover: Approx. 0.5 g each
E5EC-T
Controller: Approx. 210 g, Adapters: Approx. 4 g × 2
Terminal Cover: Approx. 1 g each
E5AC-T
Controller: Approx. 250 g, Adapters: Approx. 4 g × 2
Terminal Cover: Approx. 1 g each
Degree of protection Front panel: IP66, rear case: IP20, terminals: IP00
Memory protection Non-volatile memory (number of writes: 1,000,000)
Setup Tool CX-Thermo version 4.61 or higher
