Omron E5*C Series User Manual

6 Parameters
6 - 14
E5@C-T Digital Temperature Controllers User’s Manual (H185)
This parameter measures the heater current from the CT input used for detecting SSR short-circuits.
This parameter specifies running or stopping the program.
This parameter is used to monitor the manipulated variable for the heating control output during opera-
tion.
lcr2
Leakage Current 2 Monitor
HB and HS alarms must be supported (two CTs).
The HS Alarm Use parameter must be set to ON.
This parameter measures and displays the heater current value.
• The HS alarm is not detected if the OFF time for the control output for heating is 100 ms
or less (35 ms or less if the control period is 0.1 or 0.2 s).
• ffff is displayed when 55.0 A is exceeded.
• If an alarm is output for the HS Alarm 2 parameter, the No. 1 display will flash the
Leakage Current 2 Monitor parameter.
z Related Parameters
HS Alarm 1 (Adjustment Level): Page 6-32
HS Alarm 2 (Adjustment Level): Page 6-33
HS Alarm Use (Advanced Function Setting Level): Page 6-94
Error Display lcr2: Page A-13
r-r
Run/Reset
Program execution will start when run (run) is selected and it will stop when rst (reset) is
selected. The RST indicator will light while program operation is stopped.
The default is rst.
o
MV Monitor (Heating)
• During standard control, the manipulated variable is monitored. During heating/cooling
control, the manipulated variables on the control output (heating) is monitored.
• The parameter is masked by default and the manipulated variable is not displayed.
z Related Parameters
Parameter Mask Setting (Advanced Function Setting Level): Page 6-110
Function
Monitor
Monitor range Unit
0.0 to 55.0 A
See
See
Operation
Function
Monitor
Control Monitor range Unit
Standard −5.0 to 105.0 %
Heating/cooling 0.0 to 105.0 %
See
See
