E5@C-T Digital Temperature Controllers User’s Manual (H185)
6-3 Operation Level
6
This parameter is used to monitor the manipulated variable for the cooling control output during opera-
tion.
c-o
MV Monitor (Cooling)
The control system must be set to heating/cooling
control.
• During heating/cooling control, the manipulated variable on the control output (cooling) is
monitored.
• This parameter is masked by default and the manipulated variable is not displayed.
z Related Parameters
Standard or Heating/Cooling (Initial Setting Level): Page 6-64
Parameter Mask Setting (Advanced Function Setting Level): Page 6-110
v-m
Valve Opening Monitor A Position-proportional Model must be used.
• This parameter is used to monitor the valve opening for position-proportional control.
• The valve opening can be monitored if a potentiometer is connected and motor calibration
is executed.
z Related Parameters
Motor Calibration (Initial Setting Level): Page 6-76
Function
Monitor
Control Monitor range Unit
Heating/cooling 0.0 to 105.0 %
See
See
Function
Monitor
Control Monitor range Unit
Position-proportional control −10.0 to 110.0 %
See
See
