5 Advanced Operations
E5@C-T Digital Temperature Controllers User’s Manual (H185)
5-13 Using PID Sets
5
5-13-2 Settings for PID Sets
This section describes the procedures to make settings to use fixed PID sets and to use automatic
selection of PID sets according to zones.
Setting Example
This example shows how to set PID set 1 for program 0.
5-13-2 Settings for PID Sets
Using Fixed PID Sets
Operating Procedure
z Specifying the PID Set Number (Program Setting Level)
1 Move to the Program Setting Level. The Display Program
Selection parameter is displayed.
Program Setting Level
2 Press the U or D Key to select 0 .
The default is the currently selected program number.
3 Press the M Key several times to select the PID Set No. param-
eter.
Program Setting Level
4 Press the U or D Key to select 1 .
The default is 1.
0
d.prg
Display Program
Selection
0
d.prg
1
pid
PID Set No.
1
pid
