5 - 85
5 Advanced Operations
E5@C-T Digital Temperature Controllers User’s Manual (H185)
5-22 Logic Operations
5
5-22-2 Using Logic Operations
(4) Selecting Input Assignments
Select the input assignment for the work bit logic operation from the following settings.
Parameter name Setting range
Work Bit 1 Input Assignment A
0. Always OFF
1. Always ON
2. ON for one cycle when power is turned
ON
3. Event input 1 (external input)*
4. Event input 2 (external input)*
5. Event input 3 (external input)*
6. Event input 4 (external input)*
7. Event input 5 (external input)*
8. Event input 6 (external input)*
9. Alarm 1
10. Alarm 2
11. Alarm 3
12. Alarm 4
13. Control output (heating)
14. Control output (cooling)
15. Input error
16. HB (heater burnout) alarm
17. HS alarm
18. Auto/Manual
19. Run/Reset
20. Hold
21. PSP/FSP
22. AT Execute/Cancel
23. Ramp
24. Standby
25. Wait
26. Time signal 1
27. Time signal 2
28. Program end outputs
29. Stage
30. Program number switch, bit 0
31. Program number switch, bit 1
32. Program number switch, bit 2
33. Reserved
34. Segment number, bit 0
35. Segment number, bit 1
36. Segment number, bit 2
37. Segment number, bit 3
38. Segment number, bit 4
39. Work bit 1
40. Work bit 2
41. Work bit 3
42. Work bit 4
43. Work bit 5
44. Work bit 6
45. Work bit 7
46. Work bit 8
Work Bit 1 Input Assignment B Same as for work bit 1 input assignment A
Work Bit 1 Input Assignment C Same as for work bit 1 input assignment A
Work Bit 1 Input Assignment D Same as for work bit 1 input assignment A
