Omron E5*C Series User Manual

6 - 63
6 Parameters
E5@C-T Digital Temperature Controllers User’s Manual (H185)
6-9 Initial Setting Level
6
This parameter sets the last SP for auto-tuning when auto-tuning all PID sets.
tspu
All PID AT Upper Limit SP
Control must be set to 2-PID control and the PID
Set Automatic Selection Data parameter must not
be set to DV (deviation).
• You can set the last SP for auto-tuning when auto-tuning all PID sets.
• When you auto-tune all PID sets, auto-tuning is performed from the Fixed SP value to the
All PID AT Upper Limit SP value.
• If the Fixed SP value is greater than or equal to the All PID Upper Limit SP value (for
normal operation, it must be less than or equal), auto-tuning is performed only for the
Fixed SP value.
z Related Parameters
PID ON/OFF (Initial Setting Level): Page 6-63
AT Execute/Cancel (Adjustment Level): Page 6-27
Fixed SP (Adjustment Level): Page 6-28
PID * Automatic Selection Range Upper Limit (PID Setting Level): Page 6-49
Set Point Upper Limit (Initial Setting Level): Page 6-58
Set Point Lower Limit (Initial Setting Level): Page 6-58
cntl
PID·ON/OFF A Standard Model must be used.
• This parameter selects 2-PID control or ON/OFF control.
• The auto-tuning function can be used in 2-PID control.
z Related Parameters
AT Execute/Cancel (Adjustment Level): Page 6-27
Manual Reset Value (Adjustment Level): Page 6-38
Hysteresis (Heating) and Hysteresis (Cooling) (Adjustment Level): Page 6-38
Function
Setting
Setting range Unit Default
SP Lower Limit to SP Upper Limit EU 0
See
See
Function
Setting
Setting range Default
pid: 2-PID, onof: ON/OFF onof
See
See
