1 Introduction
1 - 8
E5@C-T Digital Temperature Controllers User’s Manual (H185)
z E5EC/AC-T
*1 The options that can be selected depend on the type of control output.
*2 The linear current output cannot be used as a transfer output.
*3 This cannot be selected if 5 (screw terminals with cover) is selected for the terminal type.
(1) (2) (3) (4) (5) (6) (7) Meaning
E 48 × 96 mm
A 96 × 96 mm
Control output 1 Control output 2
*1 R X Relay output None
*1 Q X Voltage output (for driving SSR) None
*2*1 C X Linear current output None
*1 Q Q Voltage output (for driving SSR) Voltage output (for driving SSR)
*1 Q R Voltage output (for driving SSR) Relay output
*1 R R Relay output Relay output
*2*1 C C Linear current output Linear current output
*2*1 C Q Linear current output Voltage output (for driving SSR)
*1 P R Position-proportional relay output Position-proportional relay output
44
A 100 to 240 VAC
D 24 VAC/DC
S Screw terminals
5 Screw terminals (with cover)
M Universal input
Event
inputs
Communications
HB alarm and
HS alarm
Transfer
output
For RX,
QX, RR,
QQ, QR, or
CQ
For CX or
CC
For PR
000 --- --- --- --- Selectable Selectable Selectable
004 2 RS-485 --- --- --- Selectable Selectable
005 4 --- --- --- --- Selectable ---
008 2 RS-485 1 --- Selectable --- ---
010 4 --- 1 --- Selectable --- ---
019 6 --- 1 Provided. Selectable --- ---
*3 020 4 RS-485 2 (for 3-phase
heaters)
Provided. Selectable --- ---
021 6 --- --- Provided. --- Selectable ---
022 4 RS-485 --- Provided. --- Selectable Selectable
-
-
E5 C-T
-
(1) (2) (3) (4) (5) (6) (7)
Size
Control Outputs 1 and 2
No. of auxiliary outputs
Power supply voltage
Terminal type
Input type
Options
