Omron E5*C Series User Manual

A Appendices
A - 2
E5@C-T Digital Temperature Controllers User’s Manual (H185)
A-1 Specifications
A-1-1 Ratings
Supply voltage
A in model number: 100 to 240 VAC, 50/60 Hz
D in model number: 24 VAC, 50/60 Hz; 24 VDC
Operating voltage range 85% to 110% of rated supply voltage
Power
consumption
E5CC-T
7.5 VA max. at 100 to 240 VAC, and 4.1 VA max. at 24 VDC or 2.3 W max. at 24
VDC
E5EC-T
8.7 VA max. at 100 to 240 VAC, and 5.5 VA max. at 24 VDC or 3.2 W max. at 24
VDC
E5AC-T
9.0 VA max. at 100 to 240 VAC, and 5.6 VA max. at 24 VDC or 3.4 W max. at 24
VDC
Sensor input
Temperature Input
Thermocouple: K, J, T, E, L, U, N, R, S, B, W, or PLII
Platinum resistance thermometer: Pt100 or JPt100
Infrared Temperature Sensor (ES1B): 10 to 70°C, 60 to 120°C, 115 to 165°C,
or 140 to 260°C
Analog Input
Current input: 4 to 20 mA or 0 to 20 mA
Voltage input: 1 to 5 V, 0 to 5 V, or 0 to 10 V
Input impedance
Current input: 150 Ω max., Voltage input: 1 MΩ min. (Use a 1:1 connection when
connecting the ES2-HB/THB.)
Control method 2-PID control (with auto-tuning) or ON/OFF control
Control outputs
Relay outputs
E5CC-T: SPST-NO, 250 VAC, 3 A (resistive load), Electrical life: 100,000
operations, Minimum applicable load: 10 mA at 5 V (reference value)
E5EC-T/E5AC-T: SPST-NO, 250 VAC, 5 A (resistive load), Electrical life: 100,000
operations, Minimum applicable load: 10 mA at 5 V
(reference
value)
Voltag e outputs
(for driving SSR)
E5CC-T: Output voltage: 12 VDC ±20% (PNP), Maximum load current: 21 mA,
With short-circuit protection circuit
E5EC-T/E5AC-T: Output voltage: 12 VDC ±20% (PNP), Maximum load
current: 40 mA, With short-circuit protection circuit (The
maximum load current is 21 mA for models with two control
outputs.)
Linear current
outputs
4 to 20 mA DC/0 to 20 mA DC, Load: 500 Ω max., Resolution: Approx. 10,000
Auxiliary outputs
Number of
outputs
E5CC-T: 3, E5EC-T/E5AC-T: 4
Output
specifications
SPST-NO relay outputs, 250 VAC, 2 A (resistive load),
Electrical life: 100,000 operations, Minimum applicable load: 10 mA at 5 V
(reference value)
Event inputs
Number of
inputs
2, 4, or 6 (depends on model)
External contact
input
specifications
Contact input ON: 1 kΩ max., OFF: 100 kΩ min.
Non-contact input ON: Residual voltage 1.5 V max., OFF: Leakage current
0.1 mA max.
Current flow: Approx. 7 mA per contact
Communications
Number of
channels
1 (only on models with communications)
Communications
specifications
Transmission path: RS-485
Communications method: RS-485 (2-wire, half duplex)
Synchronization: Start-stop
Baud rate: 9.6, 19.2, 38.4, or 57.6 kbps
