Omron E5*C Series User Manual

4 - 9
4 Basic Operation
E5@C-T Digital Temperature Controllers User’s Manual (H185)
4-1 Moving between Setting Levels
4
4-1-7 Moving to the Communications Setting Level
z Moving from the Operation Level to the Communications Setting Level
z Moving from the Communications Setting Level to the Operation Level
4-1-7 Moving to the Communications Setting Level
1 Press the O Key for at least 3 seconds in the Operation Level.
The No. 1 display will flash when the keys are pressed for 1 s or
longer. The display will change from the Operation Level to the
Initial Setting Level.
Operation Level
2 Press the O Key for less than 1 second in the Initial Setting
Level.
Initial Setting Level
The display will change from the Initial Setting Level to the
Communications Setting Level.
Communications Setting
Level
1 Press the O Key for less than 1 second in the
Communications Setting Level.
The display will change from the Communications Setting Level to
the Initial Setting Level.
Communications Setting
Level
2 Press the O Key for at least 1 second in the Initial Setting
Level.
Initial Setting Level
The display will change from the Initial Setting Level to the
Operation Level.
Operation Level
0
25
5
in-t
Input Type
cwf
psel
Protocol Setting
cwf
psel
5
in-t
Input Type
0
25
PV/SP
