Omron E5AR - MANUAL 2 User Manual

Section 5 Functions and Operations
5-22
Functions and
Operations
● Monitor/Setting item "PF1 setting" or "PF2 setting" can be set to "Monitor/Settings (pfdp)"
to display monitor/settings using a function key.
The content to be displayed is set for each channel in "Monitor /
Setting item 1" through "Monitor / Setting item 5" of the corresponding
function key.
The selections are shown in the following table (for the setting (or
monitor) ranges, see the respective explanations of the setting data).
◆Displaying "Monitor/Setting item"
To display "Monitor/Setting item", press the function key in
Operation, Adjustment, Adjustment 2, Bank setting, PID setting,
Approximation setting or Monitor item level.
Press the key repeatedly to scroll from "Monitor/Setting item 1" to
"Monitor/Setting item 5". After "Monitor/Setting item 5", the display
changes to the first parameter in RUN level.
* If any of settings "Monitor/Setting item 1" through "Monitor/Setting
item 5" are disabled, those settings will not appear and the display
will show the next enabled setting.
Setting
value
Description
Remarks
Monitor/Setting Display
0 Disabled
1 PV/SP/Bank No. Can set (SP) −
2 PV/SP/MV Can set (SP) −
3 PV/Deviation Monitor only −
4 Proportional band (P) Can set p
5 Integral time (I) Can set i
6 Derivative time (D) Can set d
7 Alarm 1 Can set al-1
8 Alarm upper limit 1 Can set al1h
9 Alarm lower limit 1 Can set al1l
10 Alarm 2 Can set al-2
11 Alarm upper limit 2 Can set al2h
12 Alarm lower limit 2 Can set al2l
13 Alarm 3 Can set al-3
14 Alarm upper limit 3 Can set al3h
15 Alarm lower limit 3 Can set al3l
16 Alarm 4 Can set al-4
17 Alarm upper limit 4 Can set al4h
18 Alarm lower limit 4 Can set al4l
19 Bank No. Can set bank
pf1.5
0
l.adf
Setting
item 5
pf1.1
1
l.adf
PF1 monitor / Setting item 1
pf2.5
0
l.adf
Setting
item 5
pf2.1
1
l.adf
PF2 monitor / Setting item 1
