Section 5 Functions and Operations
5-30
Functions and
Operations
● Bank No.
(Bits 0 to 2)
• The bank number is specified by the event input ON/OFF state. The
content of the event input is reflected in "Bank No." (Adjustment level).
• This setting data is an operation command that is particular to a
single channel.
• Operation is as follows based on the event input ON/OFF state.
• To use eight banks (Banks 0 to 7), 3 event input points are required.
● Run/Stop • When the event input is ON, operation is stopped and the "STOP"
indicator lights up. The content of the event input is reflected in
"Run/Stop" (Run level).
• This setting data is an operation command that is particular to a
single channel.
• Operation is as follows based on the event input ON/OFF state.
● Auto / Manual • When the event input is ON, the mode switches to manual and the
"MANU" operation indicator lights up. The content of the event input
is reflected in "Auto / Manual" (Run level).
• This setting data is an operation command that is particular to a
single channel.
• Operation is as follows based on the event input ON/OFF state.
Event input
Description
Bank No.
(Bit 0)
Bank No.
(Bit 1)
Bank No.
(Bit 2)
OFF OFF OFF Run Bank No.0
ON OFF OFF Run Bank No.1
OFF ON OFF Run Bank No.2
ON ON OFF Run Bank No.3
OFF OFF ON Run Bank No.4
ON OFF ON Run Bank No.5
OFF ON ON Run Bank No.6
ON ON ON Run Bank No.7
Event input Description
OFF Run
ON Stop
Event input Description
OFF Auto
ON Manual
