Section 8 Setting data
8-42
Setting data
Use these settings to select the output type for multi-output.
• Select pulse voltage output or linear current output.
• When pulse voltage output is selected, the output is 12 V DC, 40
mA.
• When linear current output is selected, use the "Linear current
output type" setting to select an output of 0 to 20 mA or 4 to 20 mA.
● Related setting data
"Linear current output
∗ type" (Control initial setting level) (P.8-42)
"Control/Transfer output
∗ assignment" (Control initial setting 2 level)
(P.8-46)
Use this setting to select the linear current output type.
• Select 0 to 20 mA output or 4 to 20 mA output.
● Related setting data
"Control/Transfer output
∗ assignment" (Control initial setting 2 level)
(P.8-46)
Output 1 type
Output 3 type
o1-t
o3-t
Multi-output model
l.1
Function
Setting
Setting data Setting range Units
Default value
Output type
0: Pulse voltage output
1: Linear current output
− 0
Reference
Reference
Linear current output ∗ 1 type
Linear current output
∗ 2 type
Linear current output
∗ 3 type
Linear current output
∗ 4 type
co1-t
co2-t
co3-t
co4-t
Output is current output
l.1
Function
Setting
Setting data Setting range Units
Default value
Output type
0: 0 to 20 mA
1: 4 to 20 mA
− 1
Reference
Reference
