8.10 Control initial setting level (l.1)
8-43
Setting data
• Use this setting to set upper and limits for the SP setting. The SP
can only be set between these limits. Note that if the limits are
changed and a previously set SP falls outside of the limits due to the
change, the SP will automatically change to the upper or lower limit.
• If the input type and temperature units are changed, the settings will
change to the upper and lower limits of the sensor.
• The decimal point position depends on the selected sensor. In the
case of analog input, the decimal point position is determined by the
"Decimal point position" setting.
● Related setting data
"Input
∗ type" (Input initial setting level) (P.8-36)
"Input
∗ temperature units" (Input initial setting level) (P.8-37)
Use this setting to select the control mode.
• On single-input or 4-input types, select standard control or heating/
cooling control.
• On two-input types, select standard control, heating/cooling control,
standard control with remote SP, heating/cooling control with remote
SP, proportional control, cascade standard control, or cascade
heating/cooling control.
SP upper limit
SP lower limit
sl-h
sl-l
CH
l.1
Function
Setting
Setting data Setting range Units
Default value
SP upper limit
Temperature: SP lower
limit + 1 to upper limit of
input range
Analog: SP lower limit + 1
to smaller of "99999" and
"display value equivalent
of input upper limit"
EU 1300.0
SP lower limit
Temperature: Lower limit
of input range to SP
upper limit − 1
Analog: Larger of "-
19999" and "display value
equivalent of input lower
limit" to SP upper limit - 1
EU -200.0
Reference
Reference
Control mode
mode
l.1
Function
