8.13 Display adjustment level (l.4)
8-61
Setting data
• Use this setting to select the contents of the bar graph display of the
E5AR.
• The bar graph of the E5AR is 10 segments.
• This setting is used to select the amount of time without key
operation that must elapse for the display to revert to the "PV/SP"
screen when in "Operation level", "Adjustment level", "Adjustment
level 2", "Bank setting level", "PID setting level", "Approximation
setting level", or "Monitor item level".
• When 0 is selected, the function is disabled (no auto reset).
• This setting is used to lengthen the refresh period of the monitor
value display. This only slows the display refresh cycle; it does not
affect the update period of the PV during control.
• To disable the function, select OFF.
Bar graph display item
bart
E5AR
l.4
Function
Setting
Setting range Units Default value
off : No bar graph display
1eu : Deviation 1 EU/segment
10eu : Deviation 10 EU/segment
20eu : Deviation 20 EU/segment
100eu: Deviation 100 EU/segment
o : (Standard type) Heating MV
(Position proportional type) Valve opening
c-o : (Standard type) Cooling MV
− o
Display auto-return time
ret
l.4
Function
Setting
Setting range Units Default value
0 to 99 Sec 0
Display refresh period
d.ref
l.4
Function
Setting
Setting range Units Default value
off, 0.5, 1, 2, 4 Sec 0.5
