Omron E5AR - MANUAL 2 User Manual

Setting list
A-25
Appendix
CompoWay/F
Setting data
Attributes
Variable type
Address Address
Modbus
Character Setting (monitor) value Character
Default
value
Decimal point
position
Units
Set value
D1 0000
0001 0002 0003 0004 0005 0006
1100 1102 1104 1106 1108
110A
110C
psel u-no
bps len
sbit prty sdwt
H'00000000:CompoWay/F: CWF (0) H'00000001:Modbus: MOD (1) H'00000000 to H'00000063 (0 to 99) H'00000000:9.6 (0) H'00000001:19.2 (1) H'00000002:38.4 (2) H'00000000:7 (0) H'00000001:8 (1) H'00000000:1 (0) H'00000001:2 (1) H'00000000: Noe: NONE (0) H'00000001: Even: EVEN (1) H'00000002: Odd: ODD (2) H'00000000 to H'00000063 (0 to 99)
cwf, mod 0 to 9) 9.6, 19.2, 38.4 7, 8 1, 2 none, e?en, odd 0 to 99
CWF
1
9.6
7 2
EVEN
20
−
−
kbps
Bit Bit
−
ms
− − − − − − −
Common Common Common Common Common Common Common
Protocol selection Communication unit No. Communications speed Communication data length Communication stop bit Communication parity Transmission wait time
Communication setting level
"H' -" indicated in set values (monitor values) are values set by communication (monitor).
*1 .... Changes in communication parameter settings become effective after reset.
