Setting list
A-29
Appendix
*1: When the set value of "Control / transfer output assignment" is SP
or ramp SP, the set values are initialized to the SP upper and
lower limits.
*2: When the control mode is changed, initialization takes place of
added channels in the same way as the initialization of related
parameters of "Input type" (
∆ on previous page).
*3: Based on the PID set selection data, this is (setting upper limit +
setting range
×0.1) in the case of PV and (setting range ×1.1) in
the case of DV.
*4: The default value is normally 0, however, on occasion the default
value may also be the value clamped by the SP upper and lower
limit.
*5: This becomes the clamp value only when clamped by the SP
upper and lower limit.
*6: The default value is 0.
*7: This is remote SP in the case of the secondary loop of cascade
control, and local SP in all other cases.
*8: Upper/lower limit of sensor setting range and scaling display
values 1 and 2 are initialized.
*9: If Closed/Floating is Float in position proportional control, or if
"Operation at potentiometer input error" is "Continue", this is
initialized if the integral time is 0.
*10: This is the upper and lower limit of the sensor setting range. For
temperature input, this is the range 4 - 20 mA.
*11: Initialized only if the control mode is changed to ratio control
(Temperature: Initializes to upper and lower limits of sensor
setting range. Analog: Initializes to scaling display values 1 and
2).
*12: If the applicable channel is used for heating/cooling control, this is
-100%, otherwise it is 0%. (Therefore in cascade heating/cooling
control, the primary loop is 0% and the secondary loop is -100%.)
*13: The corresponding alarm type numbers in all banks are initialized
to 0.
*14: When the input type or control mode is changed and there are
added channels, scaling display values 1 and 2 and "Decimal
point position" are not initialized.
