Section 2 Preparations
2-16
Preparations
• The number of input points of each model is as follows:
E5AR-@@@B, E5ER-@@@B: 2 points, EV1 and EV2
E5AR-@@D@, E5ER-@@D: 4 points, EV3 to EV6
E5AR-@@DB: 6 points, EV1 to EV6
• Input ratings of each input are as follows:
<Circuit schematic>
Contact ON: 1 k
Ω max., OFF: 100 kΩ or higher
No contact ON: residual voltage of 1.5 V max., OFF: leakage
current of 0.1 mA max.
E5AR
3
2
1
3
2
1
4
5
6
EV1
EV2
EV1
EV2
+
+
-
EV3
EV4
EV5
EV6
EV3
EV4
+
EV5
EV6
-
Using contact
input
Using non-contact
input
Using non-contact
input
Using contact
input
E5ER
3
2
1
3
2
1
4
5
6
EV1
EV2
EV1
EV2
+
+
-
EV3
EV4
EV5
EV6
EV3
EV4
+
EV5
EV6
-
Using contact
input
Using non-contact
input
Using non-contact
input
Using contact
input
K
E
B
E
COM
12 V
4.7 kΩ
3.9 kΩ
