F210
Setup Manual
SECTION 5
Troubleshooting and Maintenance
SECTION 5
Troubleshooting
Connection Errors (continued)
Menu Operation Errors
Parallel Interface Errors
Problem Probable cause Reference
The indicators do not turn
ON.
(for Cameras with Light
Source)
•The lighting cable is not correctly connected to the
Camera.
•Power is not being supplied to the Controller.
•When using a Camera with Intelligent Lighting, the DIP
switch pins are not set to 0.
•When using Intelligent Lighting with the F160-S2 camera
model, the number of input lines is not set to 484 lines.
p.30
p.28
Operation
Manual
Problem Probable cause Reference
The measurement results
are not displayed on the
Video Monitor.
•The Controller is not in Monitor or Run mode.
Operation
Manual
Problem Probable cause Reference
Trigger signals (input
signals) are not received.
•The cables are not correctly wired.
•The signal line is disconnected.
The status of communications can be checked with the
I/O monitor.
•The Controller is not in Monitor or Run mode.
p.38
Operation
Manual
Signals cannot be output
externally.
•The trigger signal has not been input.
•The cables are not correctly wired.
•The signal line is disconnected.
The status of communications can be checked with the
I/O monitor.
•The Controller is not in Run mode.
p.38
Operation
Manual
F210setUP.book49ページ２００３年１月２８日 火曜日 午前１１時６分
