48
SECTION 5
Troubleshooting
F210
Setup Manual
SECTION 5
Troubleshooting and Maintenance
Troubleshooting
This section lists probable corrections for common hardware problems.Please check all of the
following items before requesting repairs.
Connection Errors
Problem Probable cause
Reference
The POWER indicator is
not lit.
•The Power Supply is not connected properly.
•The supply voltage is not 24 VDC +10%/-15%.
p.30
The Video Monitor is blank.
•The power to the Video Monitor is not ON.
•The Monitor Cable is not connected properly.
•The Video Monitor is malfunctioning.
•When using an LCD Monitor, the power supply capacity is
insufficient.
p.27
The Video Monitor image is
not clear.
•There is electrical noise entering from the power supply
or cables.
•The Monitor Cable is not connected properly.
—
Cannot make key inputs
from the Console.
•The Console Cable is not correctly connected.
p.27
Camera images do not
appear on the screen
(for Cameras with Light
Source)
•The Camera Cable is not correctly connected.
•The lighting cable is not properly connected to the
Camera.
p.27
Camera images do not
appear on the screen
(when a standard CCTV
lens and lighting are used)
•The lens cap has not been removed.
•The Camera Cable is not correctly connected.
•The lens iris is opened or closed too far.
•The shutter speed is not suitable.
•The lighting method is not suitable.
p.27
p.34
