Precautions in using the Product
F210
Setup Manual
INTRODUCTION
Please observe the following precautions for safe use of the products.
Installation Environment
• Do not use the product in environments where it can be exposed to inflammable/explosive gas.
• Install the Controller so that cooling vents are not blocked.
• Do not install the product close to high-voltage devices and power devices in order to secure
the safety of operation and maintenance.
• Make sure to tighten all installation screws securely.
Power Supply and Wiring
• Make sure to use the product with the power supply voltage specified by this manual.
• Use a power supply cable and crimp terminals of the specified size.Do not simply connect the
twisted ends of the wires directly to the terminal block.
• Keep the power supply wires as short as possible (Max. 10 m).
• Use a DC power supply with countermeasures against high voltages (safe extra low-voltage
circuits on the secondary side).
p.30
• Ground the Controller’s ground terminal to less than 100 Ω.
• Use a grounding point that is as close as possible and keep the ground wire as short as
possible.
• Wire the Controller to the ground with a separate ground wire.To avoid grounding problems, do
not share the ground wire with any other devices or wire the ground to the building’s steel
framing.
• Confirm wiring again before the turning on the power .
Other
• Do not attempt to dismantle, repair, or modify the Controller.
• If you suspect an error or malfunction, stop using the Controller immediately, turn OFF the
power supply, and consult your OMRON representative.
• Do not touch fluorescent or halogen lights while the power is ON or immediately after the power
is turned OFF.
• Dispose of this product as industrial waste.
Precautions for Safe Use
Cooling vent
A label has been attached to the top cooling vent prior to shipment. It is
provided to prevent entry of wire fragments during wiring, so it should not
be removed until wiring is complete. After wiring has been completed,
remove the label for heat release.
