64
SECTION 5
Specifications
F210
Setup Manual
SECTION 5
Troubleshooting and Maintenance
Cameras
Specification
Characteristics
F150
-SL20A
F150
-SL50A
F150
-SLC20
F150
-SLC50
F160
-SLC20
F160
-SLC50
F160
-S1
F160
-S2
F150
-S1A
Current
consumption
1.4 W max. 2.4 W max. 3.4 W
max.
4.4 W
max.
1.7 W max.
1.2 W
max.
Vibration
resistance
10 to 150 Hz; half-amplitude: 0.35 mm; maximum acceleration: 50 m/s2, 10 times for 8 minutes each in 3
directions.
Shock resistance 150 m/s
2
, 3 times each in 6 directions
Ambient
temperature
Operating: 0 to 50°C (with no condensation) Storage: -25 to 60°C (with no condensation)
Ambient humidity Operating and storage: 35% to 85% (with no condensation)
Ambient
environment
No corrosive gases
Camera
materials
Cover: Galvanized steel sheet metal
Case: Die-cast aluminum alloy
Camera mounting base: Fiber-reinforced plastic (black)
Light materials Case: ABS
Transparent cover: PC
—
Weight Approx.
135 g
Approx.
135 g
Approx.
280g
Approx.
370g
Approx.
285g
Approx.
375g
Approx. 85g Approx.
80g
F150
-SL20A
F150
-SL50A
F150
-SLC20
F150
-SLC50
F160
-SLC20
F160
-SLC50
F160
-S1
F160
-S2
F150
-S1A
Camera Characteristics
Picture element 1/3” Interline CCD (reading all pixels)
Effective pixels 659 494 (H V)
Synchronization External sync. via horizontal sync signal
Shutter speed
(Electronic shutter)
F150-series: 1/100 s, 1/500 s, 1/2000 s, 1/10000 s
F160-series: 1/120 s, 1/200 s, 1/500 s, 1/1000 s, 1/2000 s, 1/4000 s, 1/8000 s, 1/20000 s
Partial scanning Disable Enable Disable
Lens mounting C mount
Lens Characteristics
Lens model F150
-LE20
F150
-LE50
F150
-LE20
F150
-LE50
F150
-LE20
F150
-LE50
—
Method Fixed focal point, fixed iris
Brightness F2.8
Focal length 13mm 6.1mm 13mm 6.1mm 13mm 6.1mm
Light Characteristics
Light model F150-LT10A F150
-LTC20
F150
-LTC50
F150
-LTC20
F150
-LTC50
—
Light source Red LED
(Peak emission
wavelength: 680 nm)
Red and green LED combination
(Peak emission wavelengths: 660 nm and
570 nm)
Light emission method
Pulse emission (synchronized with the camera shutter)
Mounting
distance
61 to
71mm
66 to
76mm
15 to
25mm
16.5 to
26.5mm
15 to
25mm
16.5 to
26.5mm
Depends on lens being used.
Field of vision 20 mm
×
20 mm
50mm
×
50mm
20 mm
×
20 mm
50mm
×
50mm
20 mm
×
20 mm
50mm
×
50mm
