n
Three-Phase 200 V
Heavy Duty Normal Duty
No.
Max Motor Capacity
kW
Rated Output
Current A
No.
Max. Motor Capacity
kW
Rated Output
Current A
20P1 0.1 0.8 20P1 0.2 1.2
20P2 0.2 1.6 20P2 0.4 1.9
20P4 0.4 3.0 20P4 0.75 3.5
20P7 0.75 5.0 20P7 1.1 6.0
21P5 1.5 8.0 21P5 2.2 9.6
22P2 2.2 11.0 22P2 3.0 12.0
24P0 4.0 17.5 24P0 3.7 17.5
n
Three-Phase 400 V
Heavy Duty Normal Duty
No.
Max. Motor Capacity
kW
Rated Output
Current A
No.
Max. Motor Capacity
kW
Rated Output
Current A
40P2 0.2 1.2 40P2 0.4 1.2
40P4 0.4 1.8 40P4 0.75 2.1
40P7 0.75 3.4 40P7 1.5 4.1
41P5 1.5 4.8 41P5 2.2 5.4
42P2 2.2 5.5 42P2 3.0 6.9
43P0 3.0 7.2 43P0 4.0 8.8
44P0 4.0 9.2 44P0 5.5 11.1
<1> Drives with these specifications do not guarantee complete protection for the specified environmental condition.
1.2 Model Number and Nameplate Check
18
SIEP C710606 33A OYMC AC Drive – J1000 User Manual
