Omron J1000 User Manual

Three-Phase 200 V / 400 V Class
B
C
D
E
D
F
A
G
J
I
H
L3
L2
L1
E
L1
PE
L3
L2
PE
A – Ground the cable shield
B – Enclosure panel
C – Metal plate
D – Grounding surface (remove any paint or sealant)
E – Drive
F – Motor cable (braided shield cable, max. 20 m)
G – Motor
H – Cable clamp
I – Max. distance between drive and noise filter
J – EMC noise filter
Figure D.4 EMC Filter and Drive Installation for CE Compliance
(Three-Phase 200 V / 400 V Class)
D.2 European Standards
214
SIEP C710606 33A OYMC AC Drive – J1000 User Manual
