2 Configuration Units
2 - 6
NA-series Programmable Terminal Hardware User’s Manual (V117)
Power Supply Connector Pin Arrangement
Reset Switch
Use a precision screwdriver or similar device with a diameter of less than 2.4 mm. The reset switch
performs the same function as cycling the power supply.
Ethernet Ports
Port Pin Arrangement and Indicator Locations
Pin No. Signal name
Name
1 +24 V +24-V input
20 V 0 V
3 FG Functional ground
Pin No. 1 2 3
Ethernet port 1
Ethernet port 2
Ethernet Port 1
Indicators
Ethernet Port 2
Indicators
ACT
indicator
LINK
indicator
ACT
indicator
LINK
indicator
