6-9 Hardware Check
6-9 Hardware Check
The hardware check is used to check the following functions.
Item Function
LCD check Checks the LCD.
Touch switch check Checks touch panel input.
6-9-1 LCD Check
This function checks whether the LCD (screen display) is operating normally.
Check the LCD by using operations from the Hardware Check Tab Page in the System Menu,
as follows:
1. Press the LCD Check Button to switch to the LCD Check Screen.
2. Press the Back Button to return to the Hardware Check Screen.
6-58
