Omron NS5-SQ00 V2 Series - Section 4 Connecting the Host to Serial Port

Section 4
Connecting the Host to Serial Port
This section describes the methods for connecting the host to the serial port of the PT.
For details on connecting through host link communications, refer to the Host Connection
Manual (Host Link). For details on Temperature Controller connections and Memory Link
communications, refer to the Host Connection Manual (Temp. Control, MemLink). For details
on connecting to another company’s PLC, refer to the Host Connection Manual (Multivendor
Connection).
4-1 1:1 Host Connection ........................................................................................................ 4-2
4-1-1 Connection Methods................................................................................................. 4-2
4-1-2 Unit Setting Methods................................................................................................ 4-4
4-2 1:N Host Connection ....................................................................................................... 4-7
4-2-1 Connection Methods................................................................................................. 4-7
4-2-2 Unit Setting Methods................................................................................................ 4-7
4-3 High-speed 1:N NT Link ............................................................................................... 4-16
4-3-1 Unit Setting Methods.............................................................................................. 4-17
4-4 Recommended Connector Cables .................................................................................. 4-24
