Appendix 8 Standard Models
Ethernet Cable (PT-to-Personal Computer)
Particular models are not specified, but use a cable that meets the following specifications.
Item Specifications
Conformance standards Conforms to IEEE 802.3 / Ethernet (10/100Base-T).
Transmission medium 2 pair Cat 3 UTP 22-26AWG, Cat 5, Cat 5e, Cat 6
Transmission distance 100 m (node-to-hub and hub-to-hub)
Connector 8-pin modular connector
RS-232C Connecting Cable
Model Specifications
AWG28 × 5P IFVV-SB Multiconductor shielded cable
Manufactured by Fujikura Densen.
CO-MA-VV-SB 5P × 28AWG Multiconductor shielded cable
Manufactured by Hitachi Densen.
Controller Link Communications Cable
Use one of the twisted-pair cables listed below as the communications cable.
Model Manufacturer Remarks
Li2Y-FCY2x0.56qmm KROMBERG & SHUBERT, Department
KOMTEC
German company
1x2xAWG-20PE+Tr.
CUSN+PVC
DRAKA CABLES INDUSTRIAL Spanish company
#9207 BELDEN American company
ESVC0.5x2C Bando Densen Co. Japanese company
Applicable Connectors for RS-232C
Name Model Specifications
XM2A-2501 25-pin type (male), Manufactured by OMRON.
XM2D-2501 25-pin type (female), Manufactured by OMRON.
(for DOS computers)
XM2A-0901 9-pin type (male), Manufactured by OMRON.
XM2D-0901 9-pin type (female), Manufactured by OMRON.
(for DOS computers)
Connector
DB-25P 25-pin type (male), Manufactured by JAE.
XM2S-2511 25-pin type, mm screws, Manufactured by OMRON.
XM2S-2513 25-pin type, inch screws, Manufactured by OMRON.
XM2S-0911 9-pin type, mm screws, Manufactured by OMRON.
XM2S-0911-E 9-pin type, mm screws, Manufactured by OMRON.
XM2S-0913 9-pin type, inch screws, Manufactured by OMRON.
Connector hood
DB-C2-J9 25-pin type, Manufactured by JAE.
Cables for CS1-series PLC Peripheral Port
Model Specifications
CS1W-CN118 Manufactured by OMRON
(CS1-series peripheral port-to-D-Sub female 9-pin connector)
A-52
