2-6SectionLamps
113
Display Functions
Normal (Standard) Lamps
The relationship between the properties of a normal (standard) lamp and the dis-
played graphic are indicated below.
Properties
General
Position Coordinates of the top left corner of the lamp display area
Size Width and height of the lamp display area (in dot units)
Frame Presence/absence of a frame for the lamp display graphic
Check mark (frame used)/No check mark (no frame)
Shape Shape of the lamp (display graphic)
Rectangle, Polygon, Circle, Sector
Color
Frame Color of the frame (valid only when a check mark is set for
Frame above). Colors other than black and white are
available with the NT31C and NT631C only.
Black/Blue/Red/Magenta/Green/Cyan/Yellow/White
ON
/Flashing
Color of the lamp in the ON or flashing states (Colors other
than black and white are available with the NT31C and
NT631C only.)
Black/Blue/Red/Magenta/Green/Cyan/Yellow/White
OFF Color of the lamp in the OFF state (Colors other than black
and white are available with the NT31C and NT631C only.)
Black/Blue/Red/Magenta/Green/Cyan/Yellow/White/
Transparent
Light Function
Address
PC Bit
Address
Allocated bit of the lamp (Allocated bit, page 114)
I/O
Comments
Comment that indicates the meaning of the allocated bit
Character string of up to 16 alphanumerics and symbols
Lamp Attribute
ON Type Display mode when the lamp is ON
Light/Flash
Guide Characters
Display Presence/absence of character string (guide characters)
attached to the lamp
Check mark (display)/No check mark (don’t display)
Type Type of character string attached to the lamp
Fixed character string, ON/OFF switching, numeral
display, or character string display
Guide character settings (Refer to Guide Character Type on page 115.)
