2-7SectionTouch Switches
139
The attributes for screen printing are as follows:
Settings
Print Screen
Printing of
Display Screen
Set whether the touch switch is to start printing or stop
printing.
Start/Abort
Relationship with Other Elements
• By using input key – string and input key – control in combination with Numeral
Input (page 192) and String Input (page 210), numeric values and character
strings can be input.
Registering these keys in windows makes it possible to switch among win-
dows as required for versatile input.
• Special touch switches with specific functions (input key – control) are auto-
matically created for the following elements.
Trend graphs (page 170), alarm list (page 182), alarm history (page 182),
thumbwheel switches (page 200), recipes (page 216)
• Touch switches overlap with other elements according to the order in which the
elements were registered on the screen with the Support Tool.
To Next Page
