Omron NT21 User Manual

2-10SectionGraphs
166
Settings (properties of each broken line)
Start Table
Entry
*1
First numeral memory table entry number of the numeral
memory table entries used to display the broken line.
Range: 0 to 1998
No. of points
*1
Number of vertices in the broken line display (one memory table
entry is used for each vertex)
NT21: 2 to 260
NT31/NT31C: 2 to 320
NT631/NT631C: 2 to 512
Interval Type Interval between numeral memory table entries in the broken
line.
Even/Uneven (cannot resize) (0 to size in the broken line
graph Direction – 1)
Line
Color Display color of the broken line (Colors other than black and
white are available with the NT31C and NT631C only.)
Black/Blue/Red/Magenta/Green/Cyan/Yellow/White
Style Line type used for the broken line graph
Solid line:
Broken line:
1-dot chain line:
2-dot chain line:
100%
*2
(Specify 100% value using either of Table Entry or Value.)
Table Entry Numeral memory table entry number checked to find the
100% value for percentage calculations
 Designate the number of the numeral memory table entry
that stores the 100% value.
Range: 0 to 1999
Value Checked to find the 100% value for percentage calculations
 Designate the 100% value (default: 100)
Range: –2147483648 to 2147483647
0%
*2
(Specify 0% value using either of Table Entry or Value.)
Table Entry Numeral memory table entry number checked to find the 0%
value for percentage calculations
 Designate the number of the numeral memory table entry
that stores the 0% value.
Range: 0 to 1999
Value Checked to find the 0% value for percentage calculations
 Designate the 0% value (default: 0)
Range: –2147483648 to 2147483647
–100%
*2
(Specify –100% value using either of Table Entry or Value.)
Table Entry Numeral memory table entry number checked to find the
–100% value for percentage calculations
 Designate the number of the numeral memory table entry
that stores the –100% value.
Range: 0 to 1999
Value Checked to find the –100% value for percentage calculations
 Designate the –100% value (default: –100)
Range: –2147483648 to 2147483647
*1: When making the setting, ensure that the total of the Start Table Entry and No. of
Points does not exceed the maximum table entry.
