2-10SectionGraphs
173
*1: The –100% value, 0% value, and 100% value must comply with the following
relationship:
–100% value < 0% value < 100% value
When a table entry is specified for the % value, the relationship above will not be
satisfied if the contents of the specified numeral memory table entry are
incorrect. In this case, the graph won’t be refreshed even if the values displayed
on the graph are changed.
Reference: The graph’s % values are always displayed with the standard display attrib-
utes. These display attributes cannot be changed.
Logging
Data Logging
Whether or not the logging function is used (Data logging
function and background function, page 177)
Check mark (logging function used)/
No check mark (logging function not used)
Background
*2
Whether or not the background function is used (Data logging
function and background function, page 177)
Check mark (background function used)/
No check mark (background function not used)
Forward
*2
Presence/absence of a touch switch to proceed to the next
page
Check mark (touch switch set)/
No check mark (touch switch not set)
Rewind
*2
Presence/absence of a touch switch to return to the previous
page
Check mark (touch switch set)/
No check mark (touch switch not set)
Clear Log
*2
Presence/absence of a touch switch to clear the logging data
Check mark (touch switch set)/
No check mark (touch switch not set)
Touch Switches for Display Function
Stop Presence/absence of a touch switch to stop data sampling
Check mark (touch switch set)/
No check mark (touch switch not set)
Clear
Display
Presence/absence of a touch switch to clear the trend graph
display
Check mark (touch switch set)/
No check mark (touch switch not set)
Continue Presence/absence of a touch switch to restart data sampling
Check mark (touch switch set)/
No check mark (touch switch not set)
The line thickness for trend graphs is fixed as 1 dot.
