2-12SectionInputting Numeric Values
193
decimal and hexadecimal, set numeral input into separate numeral memory
table entries, both allocated in the same area.
• The range of numeric values that can be input depends on the Storage Type
(BCD or Binary) of the numeral memory table entry, and the Display Type
(Decimal or Hexadecimal), and Display Sign settings made for the numeral
setting input field. For details, refer to 2-3-1 Numeral Memory Table (page 72).
• It is not possible to register multiple input fields (regardless of the type of nu-
meric key or thumbwheel) that refer to the same numeral table entry on the
same screen.
The relationship between the properties of a numeral setting input field and the
numeric values input and displayed is indicated below.
Properties
General
Position Coordinates of the top left corner of the numeral setting
input field
Font Type Font for the numerals
Standard/Half Height/Double Width
Scale Scale at which the numeric value is displayed (Enlarged
display, page 142)
11 (Equal), 12 (High), 21 (Wide), 22, 33,
44, 88
Smoothing Whether or not smoothing is used for numerals with a
scale of 22 or larger (Smoothing, page 142)
Check mark (smoothing executed)/
No check mark (smoothing not executed)
Attribute Display mode for the numerals (Display attributes and
drawing result, page 199)
Standard/Flash/Inverse Flash
Color
Foreground Display color of the numerals (Colors other than black and
white are available with the NT31C and NT631C only.)
Black/Blue/Red/Magenta/Green/Cyan/Yellow/White
Background Background color of the numerals (Colors other than
black and white are available with the NT31C and
NT631C only.)
Black/Blue/Red/Magenta/Green/Cyan/Yellow/White
Common Attributes
