Omron NT21 User Manual

2-12SectionInputting Numeric Values
194
Settings
Table Entry Number of the numeral memory table entry into which the
input numeric value is written
Range: 0 to 1999
Display Type Display format for the numeric value (Input numeric value
and stored data, page 195)
Decimal/Hexadecimal
Format (Number of digits displayed, page 194)
Integer Number of digits in the integer part of
the numeric value
Range: 1 to 10
Maximum
combined total of
Decimal Number of digits in the decimal
fraction of the numeric value
Range: 0 to 9
combined total o
f
10 digits
Limit (Upper/lower (max./min.) limit check, page 197)
Maximum Upper limit for numeric values that can be input
Minimum Lower limit for numeric values that can be input
Zero Suppression Whether or not zero suppression is used (Zero
suppression, page 144)
Check mark (zero suppression used)/
No check mark (zero suppression not used)
Display Sign Whether or not negative numbers are indicated (setting
ineffective if Hexadecimal has been set for Display Format)
(Input numeric value and stored data, page 195)
Check mark (negative numbers indicated)/
No check mark (negative numbers not indicated)
Focus Frame Presence/absence of a frame indicating that the numeral
setting input field has become ready to accept input
Check mark (frame present)/
No check mark (frame not present)
Focus Attribute Display status before the input numeric value is confirmed
(Display attributes and drawing result, page 199)
Standard/Inverse/Flash/Inverse Flash
Interlock Function
Interlock
Presence/absence of interlock control of numeral input
Check mark (interlock)/No check mark (don’t interlock)
PC address settings
PC bit address Allocated interlock bit used to enable/disable operation of
the numeral input (See Interlock Bit Allocation on page
199.)
I/O comments Comment that explains the allocated bit.
Up to 16 characters.
Background color
123456
Position
Foreground color
Number of Digits Displayed
All contents of numeral memory table entries are stored as integers. To display a
numeric value that has a decimal fraction in a numeral setting input field, set the
Decimal setting to 1 or higher to specify the number of places after the decimal
point. A decimal point is then automatically inserted.
