2-12SectionInputting Numeric Values
202
The relationship between the properties of a thumbwheel type numeral setting
input field and the numeric values input and displayed is indicated below.
Properties
General
Position Coordinates of the top left corner of the numeral setting
input field
Size Size of the input field
Small/Medium/Large
End Plate Presence/absence of end plates at either end of the
numeral setting input field
Check mark (end plates used)/
No check mark (end plates not used)
Attribute Display mode for the numerals (Display attributes and
drawing result, page 204)
Standard/Flash/Inverse Flash
Thumbwheel Color
Frame Color of the frame of the numeral setting input field (Colors
other than black and white are available with the NT31C
and NT631C only.)
Black/Blue/Red/Magenta/Green/Cyan/Yellow/White
Foreground Foreground color of the numeral setting input field (Colors
other than black and white are available with the NT31C
and NT631C only.)
Black/Blue/Red/Magenta/Green/Cyan/Yellow/White
Background Background color of the numeral setting input field (Colors
other than black and white are available with the NT31C
and NT631C only.)
Black/Blue/Red/Magenta/Green/Cyan/Yellow/White
Character Color
Foreground Display color of the numerals (Colors other than black and
white are available with the NT31C and NT631C only.)
Black/Blue/Red/Magenta/Green/Cyan/Yellow/White
Background Background color of the numerals (Colors other than black
and white are available with the NT31C and NT631C only.)
Black/Blue/Red/Magenta/Green/Cyan/Yellow/White
Common Attributes
