Omron NT21 User Manual

2-14SectionRecipes
228
Recipe Element Properties
General properties
Position Coordinates of upper left of recipe
Size of Recipe Data (Size) Length and height of recipe data display area (Unit: DPI). Display only
(editing disabled).
Show Parameters Show/Hide
Show Serial Number Show/Hide
Display Line Qty NT21: 1 to 6
NT31/31C: 1 to 11
NT631/631C: 1 to 23
No. of Parameters NT21: 1 to 6
NT31/31C: 1 to 7
NT631/631C: 1 to 15
Param Column Width 1 to 12
Record Name Width 1 to 12
Scale Scale at which the text is displayed (Enlarged display, page 99).
11 (Equal), 12 (High), 21 (Wide), 22, 33,
44, 88
Smoothing Whether or not smoothing is used for text with a scale of 22 or larger
(Smoothing, page 100).
Check mark (smoothing executed)/
No check mark (smoothing not executed)
Specifying color
Frame Color Black, blue, red, magenta (violet), green, cyan
(aquamarine), yellow, white
(Colors except white and black are available only with
the NT31C and NT631C.)
Foreground
Cl
Record name
Black, blue, red, magenta (violet), green, cyan
( i ) ll hit
g
Color
Parameter name
g()g y
(aquamarine), yellow, white
(Colors except white and black are available only with
Parameter data
(Colors
except
white
and
black
are
available
only
with
the NT31C and NT631C.)
Background
Cl
Record name
Black, blue, red, magenta (violet), green, cyan
( i ) ll hit
g
Color
Parameter name
g()g y
(aquamarine), yellow, white
(Colors except white and black are available only with
Parameter data
(Colors
except
white
and
black
are
available
only
with
the NT31C and NT631C.)
