2-14SectionRecipes
229
Setting properties
Recipe Entry 1 to 200 (recipe data number being referred to)
Note Multiple recipe elements can reference recipe
data with the same number.
Show Window/Keyboard Screen Local window 1/local window 2
Screen No.
Local 1 (keyboard) Select to control local window 1
Specify number of window screen to be controlled; 1 to
3,999
Local 2 Select to control local window 2
Specify number of window screen to be controlled; 1 to
3,999
Screen
Position
Local 1 and 2 shared
X-coordinate of bottom left corner of window
(Specification must be multiple of 20)
NT21: 0 to 240
NT31/31C: 0 to 300
NT631/631C: 0 to 620
Y-coordinate of bottom left corner of window
(Specification must be (multiple of 20)–1)
NT21: 19 to 159
NT31/31C: 19 to 239
NT631/631C: 19 to 479
Screen Attributes Window control details open (fixed)
Replace Local Window Specify operation when another window at the
specified type (local 1/local 2) is already open.
Select to enable switching, and clear to disable
switching.
Write Notification Operation
PC Bit Address Specify the PC bit address allocated to the Write Notification Flag.
I/O Comment Comment explaining details of allocated bit. Character string of 16
characters max.
Touch switches
Read/Write touch switches Select whether to enable or disable read and write functions.
Page scroll touch switches Select whether to enable or disable touch switches to scroll 1 page in
the following directions: Up, down, left, and right.
Line scroll touch switches Select whether to enable or disable touch switches to scroll 1 line in the
following directions: Up, down, left, and right.
Interlock
Interlock all recipe touch switch
operations
Select whether to enable or disable all recipe touch switch operations
(interlock function)
Checked: ON; Not checked: OFF
Host Address Setting
PC Bit Address Host bit allocated to control prohibition of all recipe touch switch
operations (interlock bit, refer to Bit Allocations)
I/O Comment Comments explaining allocated host bit address.
Character string of 16 characters max.
Words Allocated to Records
You can use recipe data to allocate words on the host for all parameters (1 or 2
words × number of parameters) in one record. You can allocate words for recipe
data in the following areas on the host (PC).
Symbol C-series PCs Allocation CV-series PCs Allocation CS/CJ-series PCs Allocation
None IR Area OK CIO Area OK CIO Area OK
H HR Area OK --- --- HR Area
Not with
Host Link
A AR Area OK Auxiliary Area No AR Area OK
