6 System Configuration and Setup
6 - 22
NX-series Safety Control Unit User’s Manual (Z930)
Use the following procedure to register variables on the Exposed Variables Tab Page when those vari-
ables are not registered as global variables. The registered exposed variables are automatically regis-
tered as global variables.
1 Double-click Exposed Variables under Configurations and Setup − Communications −
Standard − Slave I/O.
The Exposed Variables Tab Page is displayed.
2 Enter the variable name in the Name Column of the output table or input table.
The variable that you entered is registered in the exposed variable table and in the global vari-
able table.
o
Registering New Variables on the Exposed Variables Tab Page
To Next Page
