7 - 31
7 Programming
NX-series Safety Control Unit User’s Manual (Z930)
7-5 Programming Operations
7
7-5-2 Registering POUs
You can export a program to a file (extension .spg).
You can import an exported program to reuse it in another project.
Use the following procedure.
1 Right-click a program displayed under Programming − POUs − Programs in the Multiview
Explorer, and then select Export from the menu.
The Save File Dialog Box is displayed.
2 Enter a file name, and then click the Save Button.
A program file with an .spg extension is saved.
Precautions for Correct Use
• Do not delete the program CRC data that is displayed after the program is exported. It is
used to check the data when importing the program.
You can check the CRC data on the Change Tracking Tab Page or Properties Dialog Box.
• The spg program file includes information on global variables that are used as external vari-
ables.
You can export programs with Sysmac Studio version 1.17 or higher.
Exporting Programs
To Next Page
