7 Programming
7 - 32
NX-series Safety Control Unit User’s Manual (Z930)
You can import an exported program to reuse it in another project.
Use the following procedure to import a program that was previously exported.
1 Right-click Programs under Programming − POUs in the Multiview Explorer and select Import
from the menu.
The Import Dialog Box is displayed.
When you select the files to import, you can press the Shift Key or Ctrl Key to select more than
one file.
2 Select the .spg file to import, and then click the Open Button.
When external variables are used in the program to import, the following dialog box is displayed.
Select Yes to register the variables as global variables.
When the registered global variables are used as exposed variables, the following dialog box is
displayed.
Select Yes to register the variables as exposed variables.
Importing Programs
WARNING
Check during the import of the program that the CRC of the program is correct.
Serious injury may possibly occur due to loss of required safety functions.
To Next Page
