7 Programming
7 - 36
NX-series Safety Control Unit User’s Manual (Z930)
When a function block help file is imported, the following File Selection Dialog Box is displayed.
If you select a help file (.pdf extension) with the same name as the imported function block, the
specified file is copied to the save location for the user-defined help file.
A dialog box to check the CRC data is displayed.
3 Check the CRC data, and click the OK Button.
The function block is imported and added to the project.
Precautions for Correct Use
After a function block is imported, the Safety CPU Unit will be in an unvalidated state. Always
execute safety validation again.
To Next Page
