7 Programming
7 - 56
NX-series Safety Control Unit
User
’
s Manual (Z930)
The output param
eter is inserted
on a b
ranch that is created be
fore the output variable.
Use the following proced
ure to delete output p
arameters.
Method: Right-click the output par
ameter on the FBD network and
select
Delete
fr
om the menu.
•
The selecte
d output parame
ter is deleted.
Y
ou cannot select mu
ltiple parameters.
Deleting Output Parameters
255
257
