9 - 37
9 Troubleshooting
NX-series Safety Control Unit User’s Manual (Z930)
9-3 Checking for Errors with the Sysmac Studio
9
9-3-4 Error Descriptions
Event name Safety Process Data Communications Not Established,
Incorrect FSoE Slave Address Error
Event code 35230000 hex
Meaning Safety process data communications was not established with the Safety CPU Unit because of an incorrect FSoE
slave address.
Source Depends on where the Sysmac Stu-
dio is connected and the system con-
figuration.
Source details NX Unit Detection timing When safety pro-
cess data com-
munications are
established
Error attributes Level Minor fault Recovery For request to
establish commu-
nications from
Safety CPU Unit
after removing
cause of error
Log category System
Effects User program Continues. Operation The Unit stops operating and the I/O data changes to the
safe states.
System-defined
variables
Variable Data type Name
None None None
Cause and
correction
Assumed cause Correction Prevention
The setting of the FSoE slave
address in the safety process data
communications settings is different
from the setting in the Unit.
Perform the Clear All Memory opera-
tion for the Unit.
If you use a Safety I/O Unit for which
safety process data communications
were previously established in
another system, perform the Clear All
Memory operation before you use the
Unit.
Attached
information
None
Precautions/
Remarks
None
Event name Safety Process Data Communications Not Established,
Incorrect Frame Error
Event code 35240000 hex
Meaning Safety process data communications was not established with the Safety CPU Unit because an incorrect frame was
received.
Source Depends on where the Sysmac Stu-
dio is connected and the system con-
figuration.
Source details NX Unit Detection timing When safety pro-
cess data com-
munications are
established
Error attributes Level Minor fault Recovery For request to
establish commu-
nications from
Safety CPU Unit
after removing
cause of error
Log category System
Effects User program Continues. Operation The Unit stops operating and the I/O data changes to the
safe states.
System-defined
variables
Variable Data type Name
None None None
Cause and
correction
Assumed cause Correction Prevention
An incorrect frame was received in
safety process data communications.
Make sure that the system configura-
tions and model numbers agree for
the Safety CPU Unit and Safety I/O
Units.
Set the system configuration and
setup according to the corrections
that are given on the left.
There is excessive noise. Implement noise countermeasures. Implement noise countermeasures if
excessive noise caused the error.
Attached
information
None
Precautions/
Remarks
None
