Omron NX1P User Manual

65
8. Execute the program.
Transfer the program to the NX1P or change the operating mode to RUN mode to use the
Simulator in the Sysmac Studio.
9. Click the Watch Tab Page 1 Tab.
Select StartTime, EndTime, and LapTime in the variable table and drag them to the Watch
Tab Page. Change the value of input SW1 from False to True and check the value of
variable LapTime. The value of variable LapTime shows the time from when output L1
changes to TRUE to when output L1 changes to FALSE.
10. Go offline before taking the next step. Save and export the project file.
Drag
