Omron OMNUC G5 R88D-KT50F User Manual

2-73
2-6 Dimensions of Mounting Brackets (L-Brackets for Rack Mounting)
OMNUC G5-SERIES AC SERVOMOTOR AND SERVO DRIVE USER'S MANUAL
2
Standard Models and External Dimensions
R88A-TK04K
Two, M4 countersunk holes
60
15
2.5
10
2.5
5.2
10
40±0.2
36±0.2
9.5
17
19
5.2
4-R1
R2
R1 max.
R2
2-C5
Two, M4
countersunk holes
5
2.5
10
2.5
15
60
36±0.2
9.5
17
10
40±0.2
R2
R2
R1 max.
Two, 5.2-dia. holes
2-C 5
Top Dimensions Bottom Dimensions
