3-143
3-5 Servo Relay Units and Cable Specifications
OMNUC G5-SERIES AC SERVOMOTOR AND SERVO DRIVE USER'S MANUAL
3
Specifications
Position Control Unit Cable (XW2Z-@J-A18)
This cable connects a Position Control Unit (CJ1W-NC133) to a Servo Relay Unit (XW2B-
20J6-1B).
Cable types
Connection configuration and external dimensions
Wiring
Model Length (L)
Outer diameter of
sheath
Weight
XW2Z-050J-A18 50 cm
10.0 dia.
Approx. 0.1 kg
XW2Z-100J-A18 1 m Approx. 0.2 kg
L6
38
t = 11
500
1000
Position Control Unit side
CJ1W-NC133
Servo Relay Unit side
XW2B-20J6-1B
20J6-1B
CJ1W
-
NC133
Position Control Unit side
A1
A2
A8
A6
A7
A5
A9
A20
A12
A14
A11
A17
A19
A18
A15
A16
Servo Relay Unit side
Cable: AWG28 × 4P + AWG28 × 10C
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
26
24
25
Crimp
terminal
A3
A4
AWG20 Black
AWG20 Red
Number Number
