Omron OMNUC G5 R88D-KT50F User Manual

4-38
4-3 Wiring Conforming to EMC Directives
OMNUC G5-SERIES AC SERVOMOTOR AND SERVO DRIVE USER'S MANUAL
4
System Design
 Use twisted-pair cables for the power supply cables, or bind the cables.
 Separate power supply lines and signal lines when wiring.
 External Dimensions
SUP-EK5-ER-6 3SUP-HU10-ER-6
Separate the input and output. The effect of the noise filter is small.
NF
1
2
3
4
5
6
E
NF
1
2
3
4
5
6
E
AC input AC input
Ground
Ground
AC output
AC output
Twisted-pair cables Bound cables
Servo Drive
L1C
L1
L2
L3
L2C
Servo Drive
Binding
5.5
Ground
terminal
M4
Attachment
screw for
cover M3
Cover
Noise filter
unit
105
115
43
70
52
10
95
M4
50.0
60.0
12.0
10.0
11.6
13.0
75.07.0
2.0
88.0
100±2.0 53.1±1.0
5.0
2-φ4.5×6.75
2-φ4.5
6-M4
