4-52
4-3 Wiring Conforming to EMC Directives
OMNUC G5-SERIES AC SERVOMOTOR AND SERVO DRIVE USER'S MANUAL
4
System Design
Reactor to Reduce Harmonic Current
Harmonic Current Measures
 Use a Reactor to suppress harmonic currents. The Reactor functions to suppress sudden and
quick changes in electric currents.
 The Guidelines for Suppressing Harmonic Currents in Home Appliances and General Purpose
Components requires that manufacturers take appropriate remedies to suppress harmonic
current emissions onto power supply lines.
 Select the proper Reactor model according to the Servo Drive to be used.
Servo Drive Reactor
Model
Number of
power
phases
Model
Rated
current
Inductance Weight
R88D-KTA5L
Single-phase
3G3AX-DL2002 1.6 A 21.4 mH Approx. 0.8 kg
R88D-KT01L 3G3AX-DL2004 3.2 A 10.7 mH Approx. 1.0 kg
R88D-KT02L 3G3AX-DL2007 6.1 A 6.75 mH Approx. 1.3 kg
R88D-KT04L 3G3AX-DL2015 9.3 A 3.51 mH Approx. 1.6 kg
R88D-KT01H
Single-phase 3G3AX-DL2002 1.6 A 21.4 mH Approx. 0.8 kg
Three-phase 3G3AX-AL2025 10.0 A 2.8 mH Approx. 2.8 kg
R88D-KT02H
Single-phase 3G3AX-DL2004 3.2 A 10.7 mH Approx. 1.0 kg
Three-phase 3G3AX-AL2025 10.0 A 2.8 mH Approx. 2.8 kg
R88D-KT04H
Single-phase 3G3AX-DL2007 6.1 A 6.75 mH Approx. 1.3 kg
Three-phase 3G3AX-AL2025 10.0 A 2.8 mH Approx. 2.8 kg
R88D-KT08H
Single-phase 3G3AX-DL2015 9.3 A 3.51 mH Approx. 1.6 kg
Three-phase 3G3AX-AL2025 10.0 A 2.8 mH Approx. 2.8 kg
R88D-KT10H
Single-phase 3G3AX-DL2015 9.3 A 3.51 mH Approx. 1.6 kg
Three-phase 3G3AX-AL2025 10.0 A 2.8 mH Approx. 2.8 kg
R88D-KT15H
Single-phase 3G3AX-DL2022 13.8 A 2.51 mH Approx. 2.1 kg
Three-phase 3G3AX-AL2025 10.0 A 2.8 mH Approx. 2.8 kg
R88D-KT20H
Three-phase
3G3AX-AL2055 20.0 A 0.88 mH Approx. 4.0 kg
R88D-KT30H
R88D-KT50H 3G3AX-AL2110 37.0 A 0.35 mH Approx. 5.0 kg
R88D-KT75H
3G3AX-AL2220 70.0 A 0.18 mH Approx. 10.0 kg
R88D-KT150H
R88D-KT06F
3G3AX-AL4025 6.0 A 7.7 mH Approx. 2.7 kgR88D-KT10F
R88D-KT15F
R88D-KT20F
3G3AX-AL4055 10.0 A 3.5 mH Approx. 4.0 kg
R88D-KT30F
R88D-KT50F 3G3AX-AL4110 20.0 A 1.3 mH Approx. 6.0 kg
R88D-KT75F
3G3AX-AL4220 36.0 A 0.74 mH Approx. 10.0 kg
R88D-KT150F
