8-22
8-3 Vibration Suppression Parameters
OMNUC G5-SERIES AC SERVOMOTOR AND SERVO DRIVE USER'S MANUAL
8
Parameter Details
Explanation of Set Values
Set damping frequency 1 to suppress vibration at the end of the load in damping control.
Measure the frequency of vibration at the end of the load and make the setting in units of 0.1 Hz.
The range of frequency setting is 1.0 to 200.0 Hz. The function is disabled if the setting is 0 to 0.9
Hz.
Refer to "6-1 Damping Control" (P.6-1) for more information on settings.
First set the Damping Frequency 1 (Pn214). Then reduce the setting if torque saturation occurs or
increase the setting to increase operation speed. Normally, use a setting of 0.
Set value is restricted in the following manner.
Upper limit: Corresponding damping frequency
Lower limit: Damping frequency + damping filter setting ≥ 100
Refer to "6-1 Damping Control" (P.6-1) for more information on settings.
Set Damping Frequency 2 to suppress vibration at the end of the load in damping control.
Measure the frequency of vibration at the end of the load and make the setting in units of 0.1 Hz.
The range of frequency setting is 1.0 to 200.0 Hz. The function is disabled if the setting is 0 to 0.9
Hz.
Refer to "6-1 Damping Control" (P.6-1) for more information on settings.
First set the Damping Frequency 2 (Pn216). Then reduce the setting if torque saturation occurs
or increase the setting to increase operation speed. Normally, use a setting of 0.
Set value is restricted in the following manner.
Upper limit: Corresponding damping frequency
Lower limit: Damping frequency + damping filter setting ≥ 100
Set
value
Description
0 Damping filter 1 and 2 enabled
1
With external input (DFSEL1), either 1 and 3 or 2 and 4 can be selected.
· Open: Damping filters 1 and 3 enabled
· Shorted: Damping filters 2 and 4 enabled
2
With external input (DFSEL1 and DFSEL2), one of the filters 1 to 4 can be selected.
· When DFSEL1 and DFSEL2 are both open: Damping filter 1 enabled
· When DFSEL1 is shorted and DFSEL2 is open: Damping filter 2 enabled
· When DFSEL1 is open and DFSEL2 is shorted: Damping filter 3 enabled
· When DFSEL1 and DFSEL2 are both shorted: Damping filter 4 enabled
3
The damping filters are switched with position command direction.
· Forward direction: Damping filters 1 and 3 enabled
· Reverse direction: Damping filters 2 and 4 enabled
Pn214
Damping Frequency 1
Setting
range
0 to 2,000 Unit 0.1 Hz
Default
setting
0
Power OFF
and ON
−
Position
Pn215
Damping Filter 1 Setting
Setting
range
0 to 1,000 Unit 0.1 Hz
Default
setting
0
Power OFF
and ON
−
Position
Pn216
Damping Frequency 2
Setting
range
0 to 2,000 Unit 0.1 Hz
Default
setting
0
Power OFF
and ON
−
Position
Pn217
Damping Filter 2 Setting
Setting
range
0 to 1,000 Unit 0.1 Hz
Default
setting
0
Power OFF
and ON
−
To Next Page
