Page #55 background image
2-12
2-3 Standard Model Tables
OMNUC G5-SERIES AC SERVOMOTOR AND SERVO DRIVE USER'S MANUAL
2
Standard Models and External Dimensions
1,500-r/min and 2,000-r/min Servomotors and Servo Drives
* Use these combination with caution because the Servo Drive and Servomotor have different capacities.
Voltage
Servomotor
Servo Drive
Rated
output
With incremental
encoder
With absolute
encoder
Single-phase/
3-phase 200 V
1 kW R88M-K1K020H-@ R88M-K1K020T-@ R88D-KT10H
1.5 kW R88M-K1K520H-@ R88M-K1K520T-@ R88D-KT15H
3-phase 200 V
2 kW R88M-K2K020H-@ R88M-K2K020T-@ R88D-KT20H
3 kW R88M-K3K020H-@ R88M-K3K020T-@ R88D-KT30H
4 kW* R88M-K4K020H-@ R88M-K4K020T-@ R88D-KT50H
5 kW R88M-K5K020H-@ R88M-K5K020T-@ R88D-KT50H
7.5 kW --- R88M-K7K515T-@ R88D-KT75H
11 kW* --- R88M-K11K015T-@ R88D-KT150H
15 kW --- R88M-K15K015T-@ R88D-KT150H
3-phase 400 V
400 W* R88M-K40020F-@ R88M-K40020C-@ R88D-KT06F
600 W R88M-K60020F-@ R88M-K60020C-@ R88D-KT06F
1 kW R88M-K1K020F-@ R88M-K1K020C-@ R88D-KT10F
1.5 kW R88M-K1K520F-@ R88M-K1K520C-@ R88D-KT15F
2 kW R88M-K2K020F-@ R88M-K2K020C-@ R88D-KT20F
3 kW R88M-K3K020F-@ R88M-K3K020C-@ R88D-KT30F
4 kW* R88M-K4K020F-@ R88M-K4K020C-@ R88D-KT50F
5 kW R88M-K5K020F-@ R88M-K5K020C-@ R88D-KT50F
7.5 kW --- R88M-K7K515C-@ R88D-KT75F
11 kW* --- R88M-K11K015C-@ R88D-KT150F
15 kW --- R88M-K15K015C-@ R88D-KT150F
