Page #561 background image
11-2
11-1 Troubleshooting
OMNUC G5-SERIES AC SERVOMOTOR AND SERVO DRIVE USER'S MANUAL
11
Troubleshooting and Maintenance
Precautions When a Problem Occurs
When checking and verifying I/O after a problem has occurred, the Servo Drive may suddenly
start to operate or suddenly stop, so always take the following precautions.
You should assume that anything not described in this manual is not possible with this product.
Precautions
Disconnect the wiring before checking for cable breakage. If you test conduction with the cable
connected, test results may not be accurate due to conduction via bypassing circuit.
If the encoder signal is lost, the motor may run away, or an alarm may occur. Be sure to disconnect
the motor from the mechanical system before checking the encoder signal.
When measuring the encoder output, perform the measurement based on the SENGND (CN1 pin
13).
When an oscilloscope is used for measurement, it will not be affected by noise if measurements
are performed using the differential between CH1 and CH2.
When performing tests, first check that there are no persons in the vicinity of the equipment, and
that the equipment will not be damaged even if the motor runs away.
Before performing the tests, verify that you can immediately stop the machine using an emergency
stop even if it runs away.
